Description
The GCE Compact Wastewater Treatment System is an integrated solution designed for decentralized domestic and light industrial sewage treatment. It features a treatment capacity of 5 cubic meters per day (5 m³/d), with 304 stainless steel construction and external coating for enhanced corrosion resistance and aesthetics.
Key Features
– Treatment Capacity: 5 m³/day
– Material: 304 Stainless Steel
The system adopts the AAO (Anaerobic-Anoxic-Oxic) biological treatment process, which effectively removes organic matter, nitrogen, and partially phosphorus. This proven process is widely used for domestic and light industrial sewage treatment and ensures stable effluent quality.
– Surface Treatment: Anti-corrosion coating
Influent & Effluent Water Quality Indicators
|
No. |
Parameter |
Influent |
Effluent (Guaranteed Performance) |
|
1 |
pH |
6 ~ 9 |
6 ~ 9 |
|
2 |
CODCr (mg/L) |
≤ 400 |
≤ 50 |
|
3 |
BOD₅ (mg/L) |
≤ 100 |
≤ 10 |
|
4 |
NH₃-N (mg/L) |
≤ 50 |
≤ 8 |
|
5 |
TP (mg/L) |
≤ 5 |
— |
|
6 |
Fecal Coliforms |
≥ 10⁴ |
≤ 2.0 MPN/100mL |
|
7 |
Turbidity (NTU) |
— |
≤ 10 |
|
8 |
Dissolved Oxygen (mg/L) |
— |
≥ 1.0 |
System Dimensions
Length × Width × Height: 2.6m × 1.3m × 1.8m
Standard Configuration
1. Main Equipment:
– 1 Set of Integrated Treatment Unit
– 3 Submersible Sewage Pumps
– 1 Roots Blower
2. Pipes & Valves:
– Sewage Pipes
– Air Pipes
– Manual Valves
3. Instrumentation:
– 1 Flow Meter
– 2 Float Level Switches
4. Control System:
– Electrical Control Cabinet
– Power Distribution & Automatic Control System
